| Model Number | AOK-TP911-FR | ||||
|---|---|---|---|---|---|
| Brand Name | OEM | ||||
| Origin | China | ||||
| Small Orders | Accepted | ||||
Specifications
•Input: 1x USB-B upstream port for connection to the host computer
•Output:
•1x USB 2.0 port up to 480Mbps
•9x USB 3.0 port up to 5Gbps
•1x RJ45 10/100/1000Mbps
•1x DC power input port (DC5.5*2.5)
•USB-A power output: 5V2A (Max) support BC1.2
•Dimensions: 210 x 67.4 x 28 mm
•Incl. power managed control software (Standard Edition) for Windows only, features per-port power switching (PPPS) capability
Features
Supports USB hosts and devices up to USB 5Gbps
Backward compatible with USB 2.0 and USB 1.x devices
Per-port power switching on/off by using our dedicated control software
Real-time power monitoring for voltage and current on any/all ports
Individually enable/disable any of 10 downstream ports with a simple click on the control software, save a lot of plugging and unplugging
Seamless control of conference rooms, testing environments and manufacturing lines
The software allows setting passwords to prevent accidental operation.
Supply up to 2A per port
Support Ethernet 10/100/1000 Mbps
LED indicator on all ports showing power states
ESD and surge protection
Overload/overvoltage/overcurrent protection, 2.2A max/port on current protection
Alternate 2-wire terminal block power connector
DIN-rail mountable
Durable Aluminum for harsh environments
• Operating with our company's exclusively developed software, you can control power ON/OFF on any/all USB ports by just one click on the control panel
Applications
USB device manufacturing
USB device validation and development
Plug/unplug cycle testing
Functional testing
Battery charging
USB device resets
Embedded system development
Hardware-in-the-loop testing
